Airfoil® Fixed Brise Soleil

Airfoil Central Park 460x300
Airfoil_Mercedes_Benz_560x305
Airfoil Vertical 460x300
Airfoil_South_France_Supermarket_After_460x633
Airfoil_South_France_Supermarket_460x633

CS Airfoil is a fixed aluminium brise soleil (solar shading) system with all the required functionality you would expect to meet current legislation.

Designed to truly enhance and complement your exterior façade the CS fin shaped blades with accessories allow design and layout creativity.

External solar shading, like aluminium brise soleil systems are a proven method of significantly reducing solar heat gain in a building’s interior. Furthermore, it can reduce the need for air conditioning and therefore helps to reduce building CO2 emissions.

Approved Document L2 (2002)

Building Regulations Approved Document L2 (2002) provides information and guidance regarding the conservation of fuel and power in buildings.

The energy efficiency measures covered in the document include making reasonable provisions for limiting exposure to solar overheating and addressing the performance of air conditioning and mechanical ventilation systems, which have been contributing largely to the increase in carbon dioxide emissions.

  • Blades
  • Birdsmouth Brackets
  • Compound Angle Fixing Brackets
  • Parallel Off-set Fixing Brackets

A wide selection of blades offering clean lines and sleek, modern design.

AF-100 (20mmx100mm)

AF-100-_airfoil_blades

AF-150 (30mmx151mm)

AF-150-_airfoil_blades

AF-200 (38mmx203mm)

AF-200_-_airfoil_blades

AF-270
(50mmx270mm)

AF-270_-_airfoil_blades

AF-320
(53mmx320mm)

AF-320_-_airfoil_blades

AF-380 (66mmx380mm)

AF-380_-_airfoil_blades

AF-430 (70mmx430mm)

AF-430_-_airfoil_blades

Extruded aluminium birdsmouth brackets, simple and effective fixing system for CS Airfoil® blades.

Blade Type Bracket Angles Standard Bracket Width (in mm)* Fixing Hole Size (in mm)
AF-150 45° , 90° 50 6.5
AF-200 45° , 90° 100 6.5
AF-270 45° , 90° 100 8
AF-320 45° , 90° 100 8

* Brackets can be cut to custom width to suit project requirements. It should be noted, however that the width of the brackets will have a bearing on the maximum spacing. Customer bracket designs may also be possible to suit a particular project. When required, aluminium closing plates can be supplied to suit the blade profile selected.

Stainless steel Compound Angle Fixing Brackets, used when dealing with corner details and facetted elevations.

Blade Type Standard blade angles* Fixing hole quantities and size (in mm)
AF-150 45° 2×9
AF-200 45° 2×9
AF-270 45° 2×9, 4×9†
AF-320†† 45° 2×9, 4×9†
AF-380†† 45° 2×9, 4×9†
AF-430†† 45° 2×9, 4×9†

* Other angles (i.e. 30° and 60°) available on special request, please contact our Technical department for details on 01296 652800

† Four hole fixing brackets should be used where blade span exceeds 3500mm

†† Main screw ports must be tapped to suit M8x50mm long screws.

Stainless steel Parallel Off-set Fixing Brackets, used when creating straight runs of blades.

Blade Type Standard blade angles* Fixing hole quantities and size (in mm)
AF-150 45° 2×9
AF-200 45° 2×9
AF-270 45° 2×9, 4×9†
AF-320†† 45° 2×9, 4×9†
AF-380†† 45° 2×9, 4×9†
AF-430†† 45° 2×9, 4×9†

* Other angles (i.e. 30° and 60°) available on special request, please contact our Technical department for details on 01296 652800

† Four hole fixing brackets should be used where blade span exceeds 3500mm

†† Main screw ports must be tapped to suit M8x50mm long screws.

Solar Shading

Airfoil Brochure Cover

With CS Airfoil Solar Shading your design can provide lower energy costs and reduced glare, all while allowing filtered light to enter interiors and occupants to see out.

We will work with you to design the right solution for your building, from of a variety of blade sizes, outriggers and mounting options.

Download the brochure for:

  • Full list of system components
  • Suggested design layouts
